Wheel offset is one of the most important numbers in wheel fitment. A change from +45 to +38 or +35 can noticeably move a wheel outward even when the diameter stays the same, and changing width at the same time changes both inner suspension clearance and outer guard clearance.

This guide explains what positive offset means, how width and offset work together, and how to compare two wheel specifications before ordering. It is a practical starting point only: tyre width, wheel spoke shape, brakes, suspension, alignment and the individual vehicle still need to be checked.

What is wheel offset?

Wheel offset is the distance, measured in millimetres, between the wheel centreline and the hub-mounting face.

• Positive offset means the mounting face sits toward the outside face of the wheel. Higher positive numbers generally pull the wheel farther inward.
• Zero offset means the mounting face sits on the wheel centreline.
• Negative offset means the mounting face sits toward the inside of the wheel, generally pushing the wheel farther outward.

On many modern Japanese and performance cars you will commonly see positive offsets such as +45, +40, +38, +35, +30, +22 or +12. The correct number depends on the wheel width, tyre, brakes and vehicle—not offset alone.

What does +35 offset mean?

A +35 wheel has its mounting face 35 mm toward the outside of the wheel from its centreline. If you compare two wheels of the same width, a +35 wheel sits 10 mm farther outward than a +45 wheel. A +38 wheel sits 7 mm farther outward than a +45 wheel.

That simple comparison only works when width stays the same. Once width changes, half of the added width moves toward the suspension and half moves toward the guard before the offset difference is applied.

How wheel width changes the result

One inch equals 25.4 mm. If wheel width increases by 1 inch, the wheel becomes 25.4 mm wider, so approximately 12.7 mm is added to each side of the centreline before offset is considered.

For example, changing from 18x8 +45 to 18x9 +35 adds 25.4 mm of total width and reduces offset by 10 mm:

• half of the extra width = 12.7 mm;
• the 10 mm lower offset moves the wheel outward;
• the outer edge ends up about 22.7 mm farther outward;
• the inner edge ends up about 2.7 mm closer to the suspension.

This is why comparing offset without wheel width can be misleading.

A simple way to compare two wheel specs

First convert the width difference from inches to millimetres, then divide it by two.

Outer-position change: half the width increase minus the offset increase.

Inner-position change: half the width increase plus the offset increase.

When the new offset is lower, the offset change is negative. A positive outer result means more poke toward the guard. A positive inner result means the inner edge sits closer to the suspension and reduces clearance.

Example: 18x8.5 +45 → 18x9.5 +38. Width increases by 1 inch, so half the increase is 12.7 mm. Offset drops by 7 mm. The new wheel sits about 19.7 mm farther outward and about 5.7 mm closer to the suspension.

Offset does not tell you brake clearance

Two wheels with the same diameter, width and offset can have different spoke shapes and different brake clearance. This is especially important on cars with Brembo or other large brake packages.

PCD is also a separate measurement. A wheel can have a suitable offset but the wrong bolt pattern. Browse our current 5x100 wheels, 5x114.3 wheels, 5x112 wheels and 5x120 wheels by the correct PCD first, then compare width and offset.

After PCD, also confirm centre bore and wheel hardware. See our hub-centric ring & centre-bore guide and wheel-nut thread-pitch guide.

Why tyre size matters too

A wheel only describes the rim position. The tyre can extend beyond the wheel and its real measured width varies by tyre model and rim width. A wider or more square-shouldered tyre can create guard or suspension contact even when the wheel itself clears.

Lowering, camber, caster and suspension components can also change the available space. Steering clearance matters on the front axle, while suspension compression and guard clearance matter on both axles.

Common offset mistakes to avoid

• Comparing offset alone: always compare width and offset together.
• Assuming the same PCD means the wheel fits: centre bore, brake clearance, width and offset still matter.
• Copying another car from a photo: tyre size, ride height, alignment and guard work may be different.
• Ignoring spoke design: wheel-face clearance is different from barrel and offset clearance.
• Forgetting front steering clearance: a wheel can clear while parked but contact at steering lock or suspension travel.

Typical examples from popular HausofWheels fitments

On 5x100 platforms such as the Toyota GR86 and Subaru BRZ, specifications around 17x9 or 18x9.5 are common performance starting points, but the correct offset depends on tyre, suspension and intended use. See our GR86 / BRZ wheel fitment guide and browse 18-inch 5x100 wheels.

On 5x114.3 platforms such as the Nissan Silvia S15, Skyline GT-R and Mitsubishi Evo, a change from +38 toward +22 or +12 can be a major outward move depending on width. See the S15 fitment guide and browse 18-inch 5x114.3 wheels.

Wheel offset FAQ

Is a lower offset more aggressive?

When wheel width is unchanged, a lower positive offset generally moves the wheel farther outward. If width also changes, compare both numbers together.

Does +35 fit if +45 is factory?

Not automatically. On the same width it moves the wheel about 10 mm outward, but an aftermarket wheel may also be wider and have a different spoke profile. Check inner, outer and brake clearance.

Does offset affect handling?

Changing wheel position can alter track width and steering geometry, while wheel and tyre weight, tyre construction and alignment also affect how the car drives. Fitment should be chosen for the whole setup rather than appearance alone.

Can HausofWheels confirm my fitment?

We can help narrow suitable options using your vehicle and wheel specifications, but final fitment depends on the individual car. Send us the vehicle, current wheel/tyre specs, suspension setup and the wheel you are considering through our fitment enquiry.

Shop wheels by fitment

Start with the correct PCD and vehicle application, then compare width and offset. Browse Sydney Stock wheels, 5x100 or 5x114.3 options, and check each listing for its exact specification and availability.

Fitment information is a starting point, not a universal guarantee. Always confirm wheel, tyre, brake, suspension and body clearance for the exact vehicle before purchase.
