Subaru WRX VB Wheel Fitment Guide | 5x114.3 & tS Brembos

Home › Wheel Fitment Guides › Subaru WRX VB 2022+ Wheel Fitment

The 2022-on Subaru WRX VB uses a 5x114.3 PCD and works well with a wide range of genuine Japanese performance wheels, but width, offset, tyre size and brake package all matter. This guide focuses specifically on the VB chassis, including WRX TR / tS models with larger Brembo brakes.

Subaru WRX VB wheel fitment quick reference

• PCD: 5x114.3
• Centre bore: 56.1 mm
• Wheel nut thread: M12x1.25
• Common aftermarket diameter: 18 inch
• Factory offsets are relatively high, so lower-offset aftermarket wheels move noticeably farther outward

Shopping for a 2022+ WRX? Browse the dedicated Subaru WRX VB wheel collection →. You can also compare the broader WRX / STI 5x114.3 range or all 5x114.3 wheels.

Factory VB WRX wheel baseline

Depending on year and trim, the VB WRX uses 17- or 18-inch wheels with a relatively conservative factory offset. Performance-focused TR / tS variants use a larger 19-inch factory package and larger Brembo brakes. Factory dimensions are useful as a reference, but an aftermarket wheel should be checked as a complete wheel, tyre and brake package.

18x8.5 fitment for VB WRX

An 18x8.5 wheel around +40 to +48 is a useful OEM+ starting range for many street cars. It moves the wheel outward compared with the high-offset factory position without becoming as aggressive as wider 9.5-inch setups.

Owners who prioritise easy street clearance should normally stay toward the more conservative end of the offset range and verify the exact tyre width, ride height and brake package.

18x9.5 fitment for VB WRX

18x9.5 is one of the most popular performance sizes for the VB WRX. Around +38 to +45 is a common enthusiast range, with +38 producing a more outward position than +45. Tyre width, suspension height and alignment determine whether a given setup is practical on the individual car.

Lower offsets should be treated as increasingly aggressive rather than automatically bolt-on. Check outer guard clearance and inner strut clearance through steering lock and suspension compression.

WRX tS / TR Brembo wheel clearance

The tS / TR brake package changes the fitment question. PCD, diameter, width and offset do not prove that a wheel will clear the Brembo caliper because spoke curvature and barrel shape vary between wheel models.

Some 18-inch performance wheels can clear large Subaru Brembos, but this must be confirmed for the exact wheel model and face. Do not assume that every 18-inch 5x114.3 wheel fits a tS or TR simply because the nominal dimensions look correct.

For these cars, prioritise a wheel with known brake-clearance data or verify clearance before ordering.

17 vs 18 vs 19 inch wheels on a VB WRX

17 inch: more tyre sidewall, but wheel-barrel and brake clearance become more restrictive.

18 inch: the strongest all-round aftermarket choice for most VB WRX street and performance builds because it combines tyre choice, weight and appearance.

19 inch: suits owners wanting a factory tS-style diameter or a more visual street setup, but tyre sidewall and clearance margin are reduced.

Tyre and suspension considerations

A nominal tyre size does not measure exactly the same across every tyre model. Lowering springs or coilovers also alter available clearance and alignment. Plan wheel width, offset, tyre section width, ride height and camber together rather than choosing the wheel in isolation.

For an AWD Subaru, keep the overall tyre package appropriately matched and avoid mixing significantly different rolling diameters across the car.

Popular genuine JDM wheels for the VB WRX

Strong choices include RAYS Volk Racing TE37, Gram Lights 57DR / 57CR / 57NR, Enkei RPF1 and RS05RR, WORK Emotion and selected SSR models. Browse current RAYS wheels, Enkei wheels, WORK wheels and SSR wheels.

VB WRX wheel fitment FAQ

What PCD does the 2022+ Subaru WRX use?

The VB WRX uses 5x114.3 with a 56.1 mm centre bore and M12x1.25 wheel nuts.

Is 18x9.5 +38 a common VB WRX fitment?

Yes, it is a popular enthusiast specification, but it sits farther outward than a higher-offset setup and still requires tyre, ride-height and guard-clearance checks.

Will any 18-inch wheel clear WRX tS Brembos?

No. Brake clearance depends on the exact barrel and spoke profile. Confirm the individual wheel model rather than relying only on diameter and offset.

Can VA WRX / STI wheel specs be copied directly to a VB?

Some specifications overlap, but the chassis and brake packages should be checked separately. See our WRX & STI 5x114.3 guide for the broader platform overview.

Shop Subaru WRX VB wheels in Australia

Shop curated Subaru WRX VB 2022+ wheels →. Compare the broader WRX / STI 5x114.3 range or 18-inch 5x114.3 wheels. Sydney pickup is available by appointment and suitable sets can be shipped Australia-wide.

Fitment figures are researched starting points, not guarantees. Always verify the exact wheel model, tyre, brakes, suspension and body clearance on the individual vehicle before ordering.
